MODEL - WB80 - 7A
MODEL - WB80 - 7A
| PARAMETER | SPECIFICATION |
| Wire diameter | 3mm-10mm (soft wire) |
| 3mm-6mm (hard wire) | |
| MAX.wire feeding speed | 70m/min |
| Distance between the bending head and machine body | 700mm |
| Bending pin axis | 3.0KW |
| Support pin axis | 3.0KW |
| Bending head U/D axis | 3.0KW |
| Support head U/D axis | 3.0KW |
| Cutting axiss | 3.0KW |
| Wire feed axis | 4.4KW |
| Rotating wire axis | 3.0KW |
| Machine dimensions [LxWxH] | 3.3x1.66x1.6 (m) |
| Machine weight | 3000kg |
